ibaCapture-Server-1440fps
Video Recording (HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)
Basic License for Video Capturing; Record up to 1440 fps - Server license for video recording
- The number of cameras is limited by the total allowed framerate of the server license (max. 64 cameras total)
Technical Data:
- Capture Server base license for video recording from cameras and virtual iba cameras
- Video- and data capture:
- Synchronized process data acquisition between ibaCapture and ibaPDA servers
- Analysis and video display in ibaAnalyzer - Includes one Interface "ibaCapture-Interface-PDA" for synchronization with one ibaPDA Server. For every other ibaPDA server another "ibaCapture-Interface-PDA" license is required
- Requires additional interface licenses for the desired cameras:
- ibaCapture-1CAM-REC or
- ibaCapture-1CAM-DISP or
- ibaCapture-1CAM-VIRT or
- ibaCapture-1CAM-GigE - Includes 144 client Live-Streams for video live views. If necessary, the amount of allowed streams can be extended with "ibaCapture-Live-Stream Add-On" licenses. Replaying stored video is not limited.
- Supported camera types:
- Analog cameras (PAL/NTSC) either via framegrabber-board (PCIe) or analog-IP-converter (e.g. AXIS P7214)
- IP-cameras (ONVIF, AXIS), if mpeg4, h264 or h265 video codecs are supported by the camera
- GigE-Vision cameras (GenICam)
For usage the license for a supported GigE-Vision SDK is required (e.g. Pleora eBUS Runtime)
- HMI-camera (virtual) with ibaCapture-Screencam (at least v4.0.0)
- ibaVision-output (virtual camera)
Remarks:
- Supported Operating Systems:
Windows 10 (x86/x64), Windows 11 (x64), Windows Server 2016 (x64), Windows Server 2019 (x64), Windows Server 2022 (x64) - .Net-Framework 4.8 required
- When using PCIe framegrabber boards in PCs from 3rd party suppliers there might be some restrictions
- Enabled by license
- Contains software maintenance and support after the purchase for 2 years. Afterwards a software maintenance and support contract is required.
