ibaPDA-Request-DTBox-128
ibaPDA Request for Data: Dualis DTBox (HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)
Symbolic request channels - Dynamically request variables from a Dualis DTBox
A DTBox can contain up to 100 resources which contain global variables and/or a collection of programs which can in turn contain local variables.
Each resource has 4 instances of the request agent running where each instance corresponds to a different time class (to subsample the DTBox’s cycle time).
The value of this time class can be configured in ibaPDA.
Key Features:
- Request agent with:
o control path via TCP/IP from ibaPDA
o Data path to ibaPDA via UDP or reflective memory
The data path needs to be configured in the DTBox Request agent and cannot be selected in ibaPDA.
Remarks:
- Requires an ibaPDA base license!
- Please provide to us the number of the existing license container within your order that we can prepare the license extension
Status:
on request
