ibaPDA-Request-FM458/TDC

FM458/TDC request via profibus - Direct request access to FM458 or SIMATIC TDC via Profibus

Technical Data:

Free request to variables of FM458 or SIMATIC TDC via service function blocks, so called Agents
(SERPDA, SERPDB in user function block library)

For data request S7 communication is used

Data for PDA recording are distributed via profibus interface to selected profibus slaves, located whether on L2B-card or on bus module ibaBM-DPM-S / ibaBM-DP (not ibaBM-DPM-64 and ibaBM-DPM-S-64)

Special Remarks:

An ibaPDA basic license is required

For any re-order the existing license number (dongle) must be provided for to generate a new license setting for the dongle

Status:available
