ibaPDA-Request-S7-DP/PN

ibaPDA Request for Data: SIMATIC S7 system (HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)
Manufacturer: iba-ag
SKU: 31.001310

S7 symbolic request of internal variables - Data acquiring and recording with free operand/symbol selection from SIMATIC S7 PLCs via Profibus or Profinet

Technical Data:

  • Free operand/symbol selection in the address range of SIMATIC S7 PLCs via Profibus or Profinet
    ----------

Profibus:

  • Profibus slave communication via ibaCOM-L2B card:
    To request values and to aquire data for recording are done via Profibus DP
  • Profibus slave communication via ibaBM-DP / ibaBM-DPM-S bus monitor
    (not with ibaBM-DPM64 or ibaBM-DPM-S-64):
    - Requesting values from SIMATIC S7 via S7 communication (MPI,Profibus,TCP/IP)
    - Acquiring data for recording via Profibus DP with datatransfer to ibaPDA computer via fiber optic link
  • Per slave several Requestblocks (FC+DB) must be implemented into the S7 program for to manage the communication
  • If more signals per CPU are required the number of used slaves per CPU can be increased
  • Redundancy mode for ibaBM-DP/ibaBM-DPM-S is supported for the usage of S7-400H systems
    ----------

Profinet:

  • Profinet device communication via ibaBM-PN bus monitor
    - Requesting values from SIMATIC S7 via S7 communication (MPI,Profibus,TCP/IP)
    - Acquiring data for recording via Profinet with datatransfer to ibaPDA computer via fiber optic link
  • Per device several Requestblocks (FB+DB) must be implemented into the S7 program for to manage the communication

Special Remarks:

  • Requires an ibaPDA basic license
  • For Profibus either an ibaCOM-L2B card or an ibaBM-DP /ibaBM-DPM-S bus monitor connected to an ibaFOB-D card is required
  • For Profinet an ibaBM-PN bus monitor connected to an ibaFOB-D card is required
  • For any re-order the license number (dongle) of the exsting ibaPDA system must be provided for to generate a new license setting for the used dongle

Status:available
