ibaPDA-256

license with 256 measuring signals - Software system for acquisition and recording of up to 256 signals

Technical Data:

• Client-server-architecture
• Configuration of acquired signals for data gathering via IO-configurator
• Auto detect of connected iba-hardware (Plug-and-Play)
• Acquisition of max. 256 signals (analog, digital and text)
• OPC DA client and server already included
• Free combination of signals for user defined groups
• Formular editor for virtual signals
• Filtering functions and data compression possibilities
• Individually configurable online display layouts
• Continuously or triggered recording parallely in two files (optionally extendable)
• Various storage profiles
• Output of messages and events
  ....

Remarks:

• Supported operating systems: Windows 10 (x86/x64), Windows 11 (x64), Windows Server 2016 (x64), Windows Server 2019 (x64), Windows Server 2022 (x64)
• .NET Framework 4.8 required
• Enabled by license
• Contains software maintenance and support after the purchase for 2 years. Afterwards a software maintenance and support contract is required.
