ibaPDA-4096

Process Data Acquisition: Basic package
license with 4096 measuring signals - Software system for acquisition and recording of up to 4096 signals

Manufacturer: iba-ag

SKU: 30.774096

Technical Data:

Client-server-architecture
Configuration of acquired signals for data gathering via IO-configurator
Auto detect of connected iba-hardware (Plug-and-Play)
Acquisition of max. 4096 signals (analog, digital and text)
OPC DA client and server already included
Free combination of signals for user defined groups
Formular editor for virtual signals
Filtering functions and data compression possibilities
Individually configurable online display layouts
Continuously or triggered recording parallely in two files (optionally extendable)
Various storage profiles
Output of messages and events
....

Remarks:

Supported operating systems: Windows 8.1 (x86/x64), Windows 10 (x86/x64), Windows 11 (x64), Windows Server 2012 (x64), Windows Server 2012 R2 (x64), Windows Server 2016 (x64), Windows Server 2019 (x64), Windows Server 2022 (x64)
With V7.2.3 or newer .NET Framework 4.8 is required
Protected by dongle
Contains software maintenance and support after the purchase for 2 years. Afterwards a software maintenance and support contract is required.
