ibaPADU-D-8AI-U

8A+8D inputs,+/-2.5 V .. +/-60 V,16Bit ADCs, max. 40kHz - Parallel Analog Digital Unit 8 analog and 8 digital channels

Technical Specifications:

• Manufacturer: iba AG
• Input module with 8 digital and 8 analog voltage inputs
• Rugged metal case (DIN rail construction)
• Dimension (WxHxD): 2.1 in x 7.9 in x 5.6 in (53 mm x 200 mm x 141 mm)
• Fiber optic connectors with ibaNet protocol 32MBit flex and bi-directional FO connection.
• 15 devices in a 32MBit flex ring together with a Flex-master (ibaFOB-D card) are possible
• Power supply: 24V DC
• Power consumption: max. 10W
  ------
  8 Analog inputs:
• Design: Galvanically isolated, single ended, separate ADC per channel
• Resolution: 16 Bit
• Filters:
  - R/C low-pass 40 kHz (permanent)
  - Analog Antialiasing Butterworth 2nd with 20kHz and a Digital Antialiasing Filter, corner frequency 1/3 of the selected sample rate, can be switched on in addition but only together
• Input level:
  - ±2.5 V ; - ±10 V ; - ±24 V ; - ±60 V
  (max. for all ranges: ±60 V)
• Input impedance:
  - 100kOhm
  - 1 MOhm (high impedance; selectable in I/O manager of ibaPDA)
• Sample rate: max. 40 kHz, free selectable
• Frequency range: 0 Hz to 20 kHz
• Accuracy: < 0.1 % of total measuring range
• Electrical isolation AC 1.5kV
• 16-pin clamp-type terminal included in delivery
  ------
  8 Digital inputs:
• Design: Galvanically isolated, protected against reverse polarity, single ended
• Input level:
  - ±24 V, max. ±60 V
• Signal level:
  - Signal level log. 0 : > -6 V; < +6 V
  - Signal level log. 1 : < -10 V; > +10 V
• Input current: 1mA, constant
• 16-pin clamp-type terminal included in delivery

Special Remark:

• Fiber optic link to any iba component that supports 32 bit flex technology is possible, but a Flex-master (i.e. ibaFOB-D card with bi- directional FO connection) is required.
• No longer supports connection to PCMCIA-F card with a RJ11 jack

Status:available
