ibaPDA-Interface-S7-TCP/UDP

ibaPDA Interface: S7-TCP/UDP (HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)
Manufacturer: iba-ag
SKU: 31.001040

Communication interface - Communication with SIMATIC S7 300/4001200/1500, WinAC

Technical Data:

  • Communication via TCP/UDP-Protocol
  • Free selectable TCP/UDP Port
  • Number of connections (modules): 64
  • Different modules available:
    - Integer: 32 analog values (Integer) and 32 binary values
    - Real: 8, 16 or 32 analog values (Real) and 32 binary values
    - Generic: free selectable data structure
  • Data acquisition:
    - Fastest sample rate 1ms
    - Typical 10ms or slower

Special Remarks:

  • Requires a PDA basic license
  • Please provide to us the dongle number of the existing PDA license with your order that we can prepare the license extension for your dongle
  • If there are more than 64 communication connections (modules) required, the interface can be extended with additional 64 interfaces (modules) with the license "one-step-up- Interface-S7-TCP/UDP". This license extension can be used 3 times per interface and allows in total 256 connections (modules) per interface.

Status:available
