INSYS icom
.
INSYS icom is the perfect partner when it comes to remote access to machinery, plant and other equipment and transmission of their operating data. We work with commitment every day to advance digitalisation and the implementation of the IIoT
Router and gateways
With routers from INSYS icom you can network your systems quickly, reliably and securely! They have been developed for the most demanding requirements and flexible use.
Managed Services
In interaction with our routers, the user-friendly remote access solutions from INSYS icom enable you to concentrate on your core business. They create a secure VPN connection, ensure maximum availability and simplify router management.
Edge Computing
In addition, on our routers you can implement applications simply, securely and reliably. You can process machine data, connect SCADA and multi-clouds or monitor threshold values.
Sort by
Begner VPN Package With MIRO-L200
10023341BS
Industrial cellular router with NAT, VPN, firewall, 2 Ethernet Ports, 1 configurable digital input/output;
separate IP networks, user roles, variable configuration profiles; very compact housing with integrated DIN-rail or screw mounting
separate IP networks, user roles, variable configuration profiles; very compact housing with integrated DIN-rail or screw mounting
MIRO-L200
10023341
Industrial cellular router with NAT, VPN, firewall, 2 Ethernet Ports, 1 configurable digital input/output;
separate IP networks, user roles, variable configuration profiles; very compact housing with integrated DIN-rail or screw mounting
separate IP networks, user roles, variable configuration profiles; very compact housing with integrated DIN-rail or screw mounting
DIN rail adapter set MIRO
10023140
Mounting set as second DIN rail mounting option, including screws, for 35 mm DIN rails;
Dimensions of the DIN rail adapter: 65 mm high, 35 mm wide; 3 mm mounting depth on DIN rail
Dimensions of the DIN rail adapter: 65 mm high, 35 mm wide; 3 mm mounting depth on DIN rail
ECR-EW300 1.0
10021493
Industrial LAN-WLAN router with NAT, VPN, firewall,
2 LAN ports, 1 RS232, 1 RS485, 2 digital inputs, 2 digital outputs;
5 separate IP networks, user roles, variable configuration profiles, icom SmartBox
2 LAN ports, 1 RS232, 1 RS485, 2 digital inputs, 2 digital outputs;
5 separate IP networks, user roles, variable configuration profiles, icom SmartBox
ECR-LW300 1.0
10021494
Industrial LTE-WLAN router with NAT, VPN, firewall,
2 LAN ports, 1 RS232, 1 RS485, 2 digital inputs, 2 digital outputs;
5 separate IP networks, user roles, variable configuration profiles, icom SmartBox
4G/LTE: penta-band, Cat. 1, 3G/HSPA: dual-band, 2G/GSM: dual-band, GPRS/EDGE Class 12; dual SIM
2 LAN ports, 1 RS232, 1 RS485, 2 digital inputs, 2 digital outputs;
5 separate IP networks, user roles, variable configuration profiles, icom SmartBox
4G/LTE: penta-band, Cat. 1, 3G/HSPA: dual-band, 2G/GSM: dual-band, GPRS/EDGE Class 12; dual SIM
MIROdul-L100
10023100
Industrial cellular router module with NAT, VPN, firewall, 1 Ethernet Ports, 1 configurable digital input/output;
separate IP networks, user roles, variable configuration profiles; compact module for plug&play device integration
separate IP networks, user roles, variable configuration profiles; compact module for plug&play device integration
MIROdul-L200
10023343
Industrial cellular router module with NAT, VPN, firewall, 2 Ethernet Ports, 1 configurable digital input/output;
separate IP networks, user roles, variable configuration profiles; compact module for plug&play device integration
separate IP networks, user roles, variable configuration profiles; compact module for plug&play device integration
MIRO-L100
10022846
Industrial cellular router with NAT, VPN, firewall, 1 Ethernet Ports, 1 configurable digital input/output;
separate IP networks, user roles, variable configuration profiles; very compact housing with integrated DIN-rail or screw mounting
separate IP networks, user roles, variable configuration profiles; very compact housing with integrated DIN-rail or screw mounting
MRcard Fiber 1.0
10022271
MRcard with 2 SFP cages for SFP transceiver modules acc. SFP-MSA, 1000BASE-X and 1000BASE-X, 2 digital inputs
MRcard IO 1.0
10022272
MRcard with 3 analogue inputs, 1 analogue output, 4 digital inputs, 4 digital outputs (relais)
MRcard PD-A 1.1
10019434
MRcard with DSL modem, VDSL2 inkl. Vectoring, ADSL2+ Annexes A/L/M, 2 digital inputs
MRcard PD-B 1.1
10019435
MRcard with DSL modem, VDSL2 inkl. Vectoring, ADSL2+ Annexes B/J (mainly Germany, Austria, Switzerland), 2 digital inputs
MRcard PL 1.0
10017035
MRcard with cellular modem, 4G/LTE Cat. 3, 3G/UMTS/HSPA, 2G/GSM/GPRS/EDGE class 12, 2 digital inputs
MRcard PL 1.1
10023227
MRcard with cellular modem with worldwide frequency bands, 4G/LTE Cat. 4, 3G/UMTS/HSPA, 2G/GSM/GPRS/EDGE class 12, 2 digital inputs
MRcard PL450 1.0
10023900
MRcard with cellular modem including LTE450, 4G/LTE Cat 1, 2G/GSM/GPRS/EDGE class 12, 2x SIM, 2 digital inputs
MRcard PLS 1.0
10022163
MRcard with cellular modem, 4G/LTE Cat. 3, 3G/UMTS/HSPA, 2G/GSM: GPRS/EDGE class 12, RS232, 2 digital inputs, 1 digital output
