ibaPDA-Request-S7-UDP

ibaPDA Request for Data: SIMATIC S7 system (HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)
Manufacturer: iba-ag
SKU: 31.001311
S7 symbolic request of internal variables - Data acquiring and recording with free operand/symbol selection from SIMATIC S7 PLC systems via network protocol UDP

Technical Data:

  • free Operands-/symbol selection within the address range of SIMATIC S7 via Ethernet
  • Communication via UDP/IP
  • max.number of Request Modules / connections: 2
  • Per Module several Requestblocks (FBs+DB) must be implemented into the S7 program for to manage the communication
  • Special Remarks:
  • An ibaPDA basic license together with the interface "ibaPDA-Interface-S7-TCP/UDP" is required
  • For any re-order the existing license number (dongle) must be provided for to generate a new license setting for the dongle
  • In addition with the extension license "one- step-up-Request-S7-UDP" the number of useable Request-Modules can be increased
  • Status:available
