ibaPDA-Interface-Codesys-Xplorer

ibaPDA Interface: Codesys-Xplorer (HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)
Tillverkare: iba-ag
Artikelnr: 31.000002
Communication interface - Data acquiring and recording with free symbol selection from Codesys based PLC systems via standard communication interfaces, without additional communication hardware

Technical Data:

  • Interface extension for access to Codesys V2 and V3 based systems
  • Data access via TCP/IP
  • Signal selection via symbolic
  • max. number of connections / modules: 16
  • Remark:
  • Requires an ibaPDA basic license
  • Please provide with your order the dongle number of your existing ibaPDA system. The dongle number is required to generate a license upgrade for your system.
  • If there are more than 16 connections / modules required, the interface can be extended with additional 16 connections / modules with the license "one-step-up- Interface-Codesys-Xplorer". This license extension can be used 14 times per interface and allows in total 240 connections / modules per interface.
  • Status:available
