Process coupling: Profibus DP Master Card (HarmonizedCode:85176200, ECCN:N, LKZ:IE, AG:N)
Manufacturer: iba-ag
SKU: 12.114400

Profibus Master Card, 12Mbaud, PCI - Profibus Master for operation of Profibus DP Slaves

Technical Specifications:

  • Supports all standard baud rates:
    9.6 Kbaud to 12 Mbaud
  • Auto baud rate detection
  • 32-bit short PCI compatible
  • Flash memory for parameter storage
  • Standard Profibus 9-pin D-connector
  • Hardware watchdog
  • Diagnostic LED give instantaneous status of network error, DP Master, DP slave and FDL
  • Operating temperature: 0°C to 50°C (32°F to 122°F)
  • Storage temperature: -25°C to +70°C (-13°F to 158°F)

RemarksStatus:on request
