ibaPDA Interface: Ethernet Global Data Memory (HarmonizedCode:85234910, ECCN:N, LKZ:DE, AG:N)
Manufacturer: iba-ag
SKU: 31.001070
Communication interface - UDP/IP-Ethernet protocol to PDA

Technical Data:

  • Communication between ibaPDA-V6 and the following controllers via UDP/IP interface:
    - Converteam HPCi
    - GE Fanuc 9030, 9070
    - Converteam Alspa 8035
  • Requirements:
    - Only EGD data messages
    - IP Unicast addressing
    - ibaPDA as "consumer"
    - ibaPDA will be served by "producers" with data
  • Number of connections (modules): 64
  • Fastest acquisition cycle 1ms
  • Special Remarks:
  • Requires a PDA basic license
  • Please provide to us the dongle number of the existing PDA license with your order that we can prepare the license extension for your dongle
  • If there are more than 64 communication connections (modules) required, the interface can be extended with additional 64 interfaces (modules) with the license "one-step-up- Interface-EGD". This license extension can be used 3 times per interface and allows in total 256 connections (modules) per interface.
  • Status:available
