ibaPDA-Request-TDC

Simatic TDC request via FO connection - PDA Request Package for free access to communicate via fiber optic link with SIMATIC TDC, depends on the used TDC interfaces, GDM with FOB-TDC or CP53 with FOB-SD.

Key Features:

Free request to variables of SIMATIC TDC via service function blocks, so called Agents (SER04A/B in user funktion block library FBAPDA)

Communication with CPU via fiber optic links
(FOB-TDC or FOB-SD)

Signal selection with:
- Symbolic information in address book
- Drag&Drop from CFC Plan

Time synchronization with TDC

Fastest acquisition cycle 1ms

Logfile for crash analysis

Load surveillance of TDC CPU to avoid CPU overload

Extensive TDC Diagnostics

Attention:
If more than one PDA takes part at one rack link, please make sure that you use unique names for racks and processors.

Special Remarks:

FOB-TDC or FOB-SD cards required!

Status:available
